隨著羅茨風機使用時間的增加，設備出現故障的幾率也會隨著增大，從新設備購買后的安裝、設備日常維護以及設備檢修，都有些事項需要注意，做好風機安裝、日常維護、保養檢修等工作，不僅能防患于未然，還能能讓風機處于更好的運行狀態，延長風機使用壽命。我們對羅茨風機需要注意的事項在此做一下小結。

       With the increase of the service time of Roots blower, the probability of equipment failure will also increase. There are somematters needing attention in the installation, routine maintenance and overhaul of the equipment after the purchase of new equipment. Doing a good job in the installation, routine maintenance, maintenance and repair of the fan can not only prevent the trouble in the bud, but also make the fan in a better operation state, Prolong the service life of fan. We need to pay attention to the items of Roots blower here to make a summary.

　　一、關于羅茨風機的安裝：

　　1.請不要把羅茨鼓風機安裝在人員經常出入、通過的場所，避免磕碰或因設備高溫被燙傷。

　　2.風機房內請設置通風換氣扇，當溫度超過40℃，將會較大縮短風機和電機的使用壽命，尤其在夏季高溫時，有必要時請選擇水冷羅茨風機。

　　3.請不要把風機安裝在含有**溶劑、易燃性氣體和腐蝕性氣體的場所，以防火災或中毒。　　

　　I. installation of Roots blower

　　1. Please do not install roots blower in the place where people often go in and out, so as to avoid bumping or scalding due to high temperature of the equipment.

　　2. Please install ventilation fan in the fan room. When the temperature exceeds 40 ℃, the service life of the fan and motor will be greatly shortened. Especially in summer when the temperature is high, please choose if necessary Water cooling of Roots blower 。

　　3. Please do not install the fan in the place containing organic solvent, flammable gas and corrosive gas to prevent fire or poisoning.

　　二、關于羅茨風機日常維護

　　1.羅茨風機每天啟動時，按時檢查油箱的位置和油質，及時添加或更換。

　　2.應根據風機使用的現場環境，如灰塵、粉塵和設備使用頻率等，定期及時清洗和清理。

　　3.羅茨鼓風機新機運行一個月后需要換一次齒輪油，三個月后再更換新油，以后，換油周期可根據油品的質量確定，但不能超過半年。

　　4.新機運行24小時后，需調整三角皮帶松緊一次，一周后再次調整，以后經常注意觀察三角帶，當發現風機異響、大電流，需要及時檢查皮帶松緊度。

　　2. Routine maintenance of Roots blower

　　1. When roots blower starts every day, check the position and quality of oil tank on time, and add or replace it in time.

　　2. The fan should be cleaned and cleaned regularly and timely according to the site environment, such as dust, dust and equipment frequency.

　　3. The gear oil of Roots blower needs to be changed once after one month of operation and three months later. After that, the oil change period can be determined according to the quality of the oil, but not more than half a year.

　　4. After the new machine runs for 24 hours, it is necessary to adjust the V-belt tightness once, and then adjust it again after a week. In the future, pay attention to observe the V-belt frequently. When abnormal noise and large current are found in the fan, the belt tightness should be checked in time.

　　三、關于羅茨風機的檢修

　　1.對羅茨風機進行保養與檢修時，須切斷電源后進行。

　　2.非專業人員請不要擅自分解、拆解、修理和改造風機，若設備出現故障，請立即停機檢查原因，并與廠家或經銷商聯系，請專業維修人員進行檢修。

　　上海瑞柘環保設備集團是一家生產羅茨風機近15年的廠家，公司主要生產羅茨風機、真空風機(羅茨泵)、環形風機和漩渦風機、離心風機等鼓風機設備，提供服務，如果您有關于羅茨風機價格、羅茨風機選型、羅茨風機維修和羅茨風機售后等系列問題，都可以隨時聯系我們。

　　1.羅茨鼓風機的維護保養

　　(1)日常保養：日常工作中應注意軸承溫度、聲音、振動情況，檢查油標油位，油溫、進排氣壓力、電流表指數示等。

　　(2)每月檢查：有三角帶傳動的風機應定期檢查V帶的張力。

　　(3)季度檢查：每季度定期清洗過濾器，更換一次潤滑油。

　　(4)年度檢查：每年應定期清洗風機的齒輪、軸承、油密封、氣密封。檢查轉子和氣缸內部的情況，校正各部間隙。

　　2. 結論

　　羅茨鼓風機在連續使用過程中會出現不同程度的磨損，風機內腔轉子與轉子、轉子與隔板之間的各間隙是影響風機正常運行的主要原因，所以在安裝時調整風機內腔各間隙，定期潤滑風機各潤滑部位，避免出現因安裝和潤滑不良而出現風機無法正常運行的情況，就能很好地保證羅茨鼓風機的正常運行，以確保生產正常運行。羅茨鼓風機的日常維護：日常工作中要注意軸承的溫度、聲音、振動情況，檢查油位、油溫、進排氣壓力、電流表指數等。

       3. Maintenance of Roots blower

　　1. The roots blower must be maintained after the power is cut off.

　　2. Please do not disassemble, disassemble, repair and transform the fan without authorization. If the equipment fails, please stop the machine immediately to check the cause, and contact the manufacturer or dealer for maintenance.

　　Shanghai Ruizhe environmental protection equipment group is a manufacturer of Roots blower for nearly 15 years Roots Blower 、 Vacuum fan (roots pump) 、 Annular fan and Vortex fan 、 Centrifugal fan Wait for the blast Machine equipment, provide service if you have about Price of Roots blower 、 Selection of Roots blower 、 Roots blower maintenance And Roots fan after-sales and other issues, you can contact us at any time.

　　羅茨鼓風機的使用維護及保養

　　(1)所輸送氣體如含有雜質，必須預先加以凈化，以免損壞零件及轉子平衡。

　　(2)檢查風機管道的安裝是否符合要求，風機主軸的轉向是否正確。

　　(3)檢查稀油站與鼓風機、與高位油箱、與儀表盤及電器控制柜的連接是否正確，向稀油站油箱注人適量的32號或46號潤滑油。

　　(4)先啟動稀油站，查看潤滑油是否足量連續地達到鼓風機左、右軸承位，確信潤滑油已達到鼓風機左、右軸承位后，再啟動電機(若電機軸承為滑動軸承，還必須保證潤滑油足量連續地達到電機軸承位后方能啟動電機)。

　　(5)開車前必須關閉進風口(或出風口閥門)，開車后逐漸打開，一直調到所需工況，但不得超過電機負荷。

　　(6)鼓風機運轉時要注意風機和電機內部應無異響，是否漏油，是否有過大振動，軸承溫升是否過高，電機電流是否過大，地腳松動等不正常現象，如果有上述現象應及時停車排除。

　　(7)不允許鼓風機在性能不穩定的喘振區域工作。

　　(8)應定期清除聚集在轉子部分的氣體雜質和污垢，以免影響轉子平衡產生振動。

　　(9)拆卸轉子須將機殼中分面及軸承上蓋拆開后整體吊出，檢查葉輪、葉片表面、密封圈、軸襯等零部件磨損情況，檢查葉輪鉚釘有無松脫，潤滑系統是否可靠，以及管道接頭有無滲漏。清除風機流道內積留的灰塵和油污。檢查期限應根據情況擬訂，但每年不得少于兩次，每次檢查應特別仔細，并做好記錄。

　　(10)鼓風機長期不使用時，就定期將轉子旋轉120℃或180%，以防主軸彎曲。

　　(11)拆換軸承箱軸承時，應注意軸承裝配位置，并按原位置裝好。

　　(12)葉輪輪毅端面與密封條應保持間隙為0.07-0.巧mm，葉輪進口圈外面與密封條的間隙為0.1一0.2mm，間隙過大會產生泄漏。

Use and maintenance of Roots blower

　　(1) if the delivered gas contains impurities, it must be purified in advance to avoid damaging the balance of parts and rotors.

　　(2) check whether the installation of fan pipe meets the requirements and whether the rotation direction of fan spindle is correct.

　　(3) check whether the connection between the thin oil station and the blower, the high-level oil tank, the instrument panel and the electrical control cabinet is correct, and inject an appropriate amount of 32 or 46 lubricating oil into the oil tank of the thin oil station.

　　(4) start the thin oil station first, check whether the lubricating oil continuously reaches the left and right bearing positions of the blower, and then start the motor after making sure that the lubricating oil has reached the left and right bearing positions of the blower (if the motor bearing is a sliding bearing, it is also necessary to ensure that the lubricating oil continuously reaches the motor bearing position before starting the motor).

　　(5) before start-up, the air inlet (or outlet valve) must be closed, and it shall be opened gradually after start-up until the required working condition is reached, but the motor load shall not be exceeded.

　　(6) during the operation of the blower, attention should be paid to whether there is abnormal noise inside the fan and motor, whether there is oil leakage, whether there is excessive vibration, whether the temperature rise of bearing is too high, whether the motor current is too large, and the foundation is loose. If there are such abnormal phenomena, stop the machine in time to eliminate them.

　　(7) the blower is not allowed to work in the surge area with unstable performance.

　　(8) the gas impurities and dirt accumulated in the rotor should be removed regularly to avoid affecting the balance of the rotor and causing vibration.

　　(9) to dismantle the rotor, the casing split and bearing upper cover shall be removed and lifted out as a whole. The wear of impeller, blade surface, sealing ring and shaft lining shall be checked. The impeller rivet shall be checked for looseness, whether the lubrication system is reliable, and whether the pipe joint has leakage. Remove the dust and oil dirt in the fan channel. The inspection period shall be worked out according to the situation, but it shall not be less than twice a year. Each inspection shall be particularly careful and recorded.

　　(10) when the blower is not used for a long time, rotate the rotor at 120 ℃ or 180% regularly to prevent the main shaft from bending.

　　Pay attention to the original position of bearing box when assembling.

　　(12) the clearance between impeller hub end face and sealing strip should be 0.07-0 The clearance between the outside of impeller inlet ring and sealing strip is 0.1-0.2mm. If the clearance is too large, leakage will occur.
